The multifunctional drum tipper is widely used in conveying and feeding of powder, granule and tablets stored in drum. It can be used for: pretreatment feeding, coating machine feeding, packaging machine feeding, reactor feeding, isolator feeding and so on. Used for conveying or feeding powders or granules and tablets.Equipped with a barrel feeding mechanism to further optimize the feeding method and make feeding more flexible.
|
Dimensions(mm) |
1160*980*1830 |
|
Feeding height(mm) |
1260-1400 |
|
Feeding width(mm) |
760-500 |
|
Air supply(Mpa) |
0.6-0.8 |
|
Air consumption(m³/per time) |
0.2 |
|
Discharging angle |
30 degree past horizontal |
|
Load capacity(KG) |
150 |
|
Loading bucket(mm) |
Diameter 500-600 Height450-600 |
|
Noise dB(A) |
≤75 |
